Product Overview
The GSC32 pneumatic tensioning tool is a sturdy and high-efficiency pneumatic device, specifically engineered for high-performance steel strapping scenarios. Thanks to its outstanding tensioning force and dependable performance, it has become a must-have tool in tough industrial settings. One of its major advantages is that it doesn’t depend on any external power supply—instead, it runs entirely on compressed air. This design not only boosts its adaptability but also makes it simpler to operate.
The GSC32 is crafted to work with steel strapping that has a width between 19 and 32 mm and a thickness ranging from 0.8 to 1.2 mm, which makes it perfect for heavy-duty strapping and palletizing work. Its strong performance guarantees that even the most difficult strapping tasks can be finished accurately and quickly. What’s more, the tool adopts semi-automatic operation: this not only ensures that every result is consistent but also greatly lessens operator tiredness, allowing for comfortable use even during long working hours.
Durability is a core design principle of the GSC32. It is made from high-grade materials, enabling it to stand up to the harsh conditions of industrial use. Additionally, it features a user-friendly design with easy-to-understand controls, so operators with different skill levels can quickly get the hang of using it.
Product Parameters
| model |
pneumatic steel tensioner GSC32 |
| Applicable packing strap |
steel strap |
| Air pressure |
0.4 ~ 0.6 Mpa |
| Tape size |
(19-32)x(0.8-1.2)mm |
| Tensioning speed |
2m/min. |
| Tension |
≥10kN/0.6Mpa |
| N.W. |
4.8kgs |
Product Features
Power Source: Compressed air (operating pressure: 0.4–0.6 MPa)
Strapping Compatibility: Steel strapping with widths of 19-32 mm and thicknesses of 0.8-1.2 mm
Tension Force: ≥9.8 KN (at 0.6 MPa)
Tensioning Speed: 5.3 m/min
Tool Weight: 4.8 kg (lightweight for portability)
Special Features: Semi-automatic operation, durable construction, ergonomic design
The use of GSC32 Pneumatic Tensioning Tool
The GSC32 is engineered for 32 mm wide steel strapping, making it ideal for heavy-duty applications in industries such as steel manufacturing, metal processing,
lumber, construction, and logistics. Its pneumatic operation ensures consistent performance in environments like warehouses, manufacturing plants, and
distribution centers where compressed air is readily available. The tool excels in securing metal coils, construction materials, heavy machinery, and large industrial
products, providing reliable load stability during storage and transportation.
